Product Introduction:
Battery locomotives are used for gas and coal dust accumulated transportation and roadway transportation. Our battery locomotives have 2.5T to 55T, which equipped with battery pack as energy with no limited of distance. Main features: small overall dimensions, short wheelbase, flexible, higher brake fast and reliable, simple structure, easy maintenance, suitable for small and medium-sized mine transportation.
8T battery locomotive has three models: normal, safety, explosion-proof.
Main features: small overall dimensions, short wheelbase, flexible, higher brake fast and reliable, simple structure, easy maintenance, suitable for small and medium-sized mine transportation.
Technical Performances for Battery Locomotive CTY(L)8
|
Model Name
|
CTY(L)8/6,7,9GB
|
|
Adhesive Weight
|
8 tons
|
|
Track Gauge
|
600, 762 or 900mm
|
|
Traction
|
11.18kN
|
12.83kN
|
|
Max. Traction
|
19.62kN
|
|
Speed
|
6.2km/h
|
7.5
km/h
|
7.8
km/h
|
|
Power Supply Device
|
Voltage
|
110V
|
132V
|
140V
|
144V
|
|
Capacity
|
440Ah
|
|
Power
|
11kW*2
|
15kW*2
|
|
Size
|
Length
|
4430mm
|
4420mm
|
|
Width
|
1054, 1356 or 1356mm
|
|
Height
|
1600mm
|
1600mm
|
|
Wheelbase
|
1100mm
|
1150mm
|
|
Wheel Diameter
|
Φ680mm
|
Φ680mm
|
Φ600mm
|
|
Min. Turning Radius
|
7m
|
|
Electromechanical Controller
|
IGBT or AC Converter
|
|
Brake
|
Mechanical and Pneumatic Brake
|
|
|
|
|
|
|
|
