Product Introduction:
Battery locomotives are used for gas and coal dust accumulated transportation and roadway transportation. Our battery locomotives have 2.5T to 55T, which equipped with battery pack as energy with no limited of distance. Main features: small overall dimensions, short wheelbase, flexible, higher brake fast and reliable, simple structure, easy maintenance, suitable for small and medium-sized mine transportation.
5T battery locomotive has three models: normal, safety, explosion-proocf.
Main features: small overall dimensions, short wheelbase, flexible, higher brake fast and reliable, simple structure, easy maintenance, suitable for small and medium-sized mine transportation.
Technical
Performances for Battery Locomotive CTY5
|
Model Name
|
CTY5/6, 7, 9GB
|
|
Adhesive Weight
|
5 tons
|
|
Track Gauge
|
600, 762 or 900mm
|
|
Traction
|
7.06kN
|
|
Max. Traction
|
12.26kN
|
|
Speed
|
7km/h
|
|
Power Supply Device
|
Voltage
|
90V
|
|
Capacity
|
385Ah
|
|
Power
|
7.5 kW*2
|
|
Size
|
Length
|
2850mm
|
|
Width
|
920, 1082 or 1220mm
|
|
Height
|
1550mm
|
|
Wheelbase
|
850mm
|
|
Wheel Diameter
|
Φ520mm
|
|
Min. Turning Radius
|
6m
|
|
Electromechanical Controller
|
Resistance or IGBT
|
|
Brake
|
Mechanical Brake
|
|
|
|
|
