Product Introduction:
Battery locomotives are used for gas and coal dust accumulated transportation and roadway transportation. Our battery locomotives have 2.5T to 55T, which equipped with battery pack as energy with no limited of distance. Main features: small overall dimensions, short wheelbase, flexible, higher brake fast and reliable, simple structure, easy maintenance, suitable for small and medium-sized mine transportation.
2.5T battery locomotive has three models: normal, safety, explosion-proof.
Main features: small overall dimensions, short wheelbase, flexible, higher brake fast and reliable, simple structure, easy maintenance, suitable for small and medium-sized mine transportation.
Technical Performances for Battery Locomotive CTY2.5
|
Model Name
|
CTY2.5/6, 7, 9GB
|
|
Adhesive Weight
|
2.5 tons
|
|
Track Gauge
|
600, 762 or 900mm
|
|
Traction
|
2.55kN
|
|
Max. Traction
|
6.13kN
|
|
Speed
|
4.54km/h
|
|
Power Supply Device
|
Voltage
|
48V
|
|
Capacity
|
330Ah
|
|
Power
|
3.5kW*1
|
|
Size
|
Length
|
2360mm
|
|
Width
|
914, 1076 or 1214mm
|
|
Height
|
1550mm
|
|
Wheelbase
|
650mm
|
|
Wheel Diameter
|
Φ460mm
|
|
Min. Turning Radius
|
5m
|
|
Electromechanical Controller
|
Resistance or IGBT
|
|
Brake
|
Mechanical Brake
|
|
|
|
|
