12T Battery Locomotive
Product Introduction:
Battery locomotives are used for gas and coal dust accumulated transportation and roadway transportation. Our battery locomotives have 2.5T to 55T, which equipped with battery pack as energy with no limited of distance. Main features: small overall dimensions, short wheelbase, flexible, higher brake fast and reliable, simple structure, easy maintenance, suitable for small and medium-sized mine transportation.
8T battery locomotive has three models: normal, safety, explosion-proocf.
Main features: small overall dimensions, short wheelbase, flexible, higher brake fast and reliable, simple structure, easy maintenance, suitable for small and medium-sized mine transportation.

Technical Performances for Battery Locomotive CTY(L)12

Model Name

CTY(L)12/6, 7, 9GB

Adhesive Weight

12 tons

Track Gauge

600, 762 or 900mm

Traction

16.48kN

Max. Traction

29.43kN

Speed

8.7km/h

Power Supply Device

Voltage

192V

Capacity

560Ah

Power

22kW*1

Size

Length

5100mm

Width

1050, 1212 or 1350mm

Height

1600mm

Wheelbase

1220mm

Wheel Diameter

Φ680mm

Min. Turning Radius

10m

Electromechanical Controller

IGBT or AC Converter

Brake

Mechanical and Pneumatic Brake
