3T Trolley Locomotive

News

Address: Innovation Building,No.9 Xiaotan Road,High-tech Zone,Xiangtan,Hunan,China
Phone: 86-731-58568676
Fax: 86-731-58568676
Post: 411100

Current:Home

Product Introduction:
Trolley locomotives are used for the no-gas mine, level one, level two gas mine and underground mine with fresh wind flow. Our trolley locomotives have 1.5T to 60T, which suitable for 100V, 250V voltage. Main features: large traction, high speed, stable operation, flexible, two levels of transmission, long service life, high efficiency.

3T (250V) trolley locomotive has step-less speed regulation and step speed regulation two kinds of speed adjustment.
The braking system adopts mechanical brake.
Features: large traction, high speed, stable operation, flexible, two levels of transmission, long service life, high efficiency.

Technical Performances for Trolley Locomotive CJY3

Model Name

CTY3/6, 7, 9G

Adhesive Weight

3 tons

Track Gauge

600, 762 or 900mm

Traction

6.1kN

5.74kN

Max. Traction

7.36kN

Speed

10.6km/h

7.5km/h

DC Voltage

550V

250V

Power

12kW*1

6.5kW*2

Size

Length

2700mm

2750mm

Width

940, 1082 or 1220mm

Height

1550mm

Wheelbase

816mm

850 mm

Wheel Diameter

Φ650mm

Φ520 mm

Pantograph

1800~2000mm

Min. Turning Radius

5.7m

6m

Electromechanical Controller

Resistance or IGBT Converter

Brake Mode

Mechanical Brake

Model Name		CTY3/6, 7, 9G
Adhesive Weight		3 tons
Track Gauge		600, 762 or 900mm
Traction		6.1kN	5.74kN
Max. Traction		7.36kN
Speed		10.6km/h	7.5km/h
DC Voltage		550V	250V
Power		12kW*1	6.5kW*2
Size	Length	2700mm	2750mm
	Width	940, 1082 or 1220mm
	Height	1550mm
	Wheelbase	816mm	850 mm
	Wheel Diameter	Φ650mm	Φ520 mm
	Pantograph	1800~2000mm
Min. Turning Radius		5.7m	6m
Electromechanical Controller		Resistance or IGBT Converter
Brake Mode		Mechanical Brake
